Description
SPECIAL FEATURES
Compact Design
Low Cost Version
The Diaphragm is welded to the Body
To ensure separation of the filling fluid
from the process medium
SPECIFICATION
Process Temperature : -40?C to 200?C or as per fill fluid _x000B_Instrument Connection : 1/4″ NPT (F)
Process Connection: 1/4″ NPT (M)
Fill Liquid : Silicon Oil -DC 200
Diaphragm: AISI 316L SS
Body: AISI 316 SS
APPLICATIONS
Diaphragm seals are designed to Isolate the sensing element of Pressure Gauges and Pressure from process fluids that they may be Corrosive, Viscous,Sedimentous and / or with high Temperature
