Description
SPECIAL FEATURES
Phenolic Case With Solid Front Design
Blow out back
Standard followed ASME-B.40.1
Helium Leak Tested
Built in Stabilizer Movement
Ready For Oxygen Use
Internal Vacuum /Over Pressure Stops
IP 66
SPECIFICATION
Ambient Temperature: -4?(-20?) to+150?(+65?)
Process Temperature: Max.392?(200?)
Operating Pressure Range: 75% of scale value
Over Pressure Limit: 150% of Max.scale value
Case & Bezel: Phenolic
Joints: Tig Argon Arc Welding
Protection: IP 66
Socket: AISI 316L
Bourdon: AISI 316L
Movement: AISI 304
Dial: Aluminum
Pointer: Micro Zero Adjustable
Window: Safety Glass
Gasket: Viton
Ranges: Vacuum to 40,000psi
ACCURACY AS PER ASME B.40.1
4.5″ : 0.5-0.5-0.5 (Grade 2A)
