Description
SPECIAL FEATURES
- Can be adjusted on zero and full-scale output
- High Stability ,High Reliability
- Short Circuit Protection and reverse polarity protection
- Measurable Gauge Pressure, Absolute Pressure & Seal Reference pressure.
SPECIFICATION
- Pressure Range :-1…0∼0.1…1000 bar
- Over Load : 2 times @ FS 1100 bar (Take the small value)
- Pressure Type : Gauge , Absolute or Sealed Gauge
- Output Type : Current Type , Voltage Type
- Power Supply : Current Type – 9∼30VDC Voltage Type – 12∼30VDC
- Output Signal : Current Type – 4mA∼20mA DC (2 Wire) Voltage Type – 0/0.5/1 V ∼ 5/4.5/10 VDC ( 3 wire) Compensation
- Temperature : 14℉ (-10℃) ∼ 176℉ (80℃) Operating Temperature : -22℉(-30℃) ∼ 176℉(80℃) Storage Temperature : -40℉ (-40℃) ∼ 257℉ (125℃) Housing : SS
- Sensor : SS 316L
- Seal Ring : Viton
- Cable : DIA 7.5mm Special cable for Polyethylene Protection Class : IP 65 (Plug) , IP 68 (Cable)
