Description
SPECIAL FEATURES
- Stainless Steel Case & Stem
- Bottom/Back/Every Angle Entry
- Silicon Oil Filled ( Optional)
- With or Without Thermowell
- External Zero Adjustable (Optional)
- Standard Followed En13190
SPECIFICATION
- Accuracy : 1 as per EN 13190
- Ambient Temperature: -13?F (-25?C) to 108?F (60?C)
- Operating Pressure : 25bar (Without Thermowell)
- Stem Diameter: 8mm
- Case & Bezel: AISI 304 SS (Bayonet Type)
- Stem Connection : AISI 316 SS
- Joint: Tig Argon Arc Welding
- Sensing Element: Coiled Bimetal
- Protection: IP 65 ( EN 60529 /IEC 529)
- Dial: Aluminium
- Pointer: Aluminium
- Window: Safety Glass
- Gasket: NBR
APPLICATIONS
- Chemical / Refinery / Fertilizer / Petrochemicals /
- Pharmaceutical / Power /Cement / Sugar /
- Food & Beverages / Pulp & Paper & Allied
- Process Industries which are having Corrosive
- Media / Environment
