Description
SPECIAL FEATURES
Nominal Pressure up to 400 bar
7 different selectable setting ranges
over pressure up to 600 bar
below types & Piston type models
STANDARD VERSION
Overload Protector Type: E01 Bellow Type
E02 Piston Type
Adjustable Range: E01 600 mbar to 4 bar
E02 6 bar to 400 bar
?O? Ring : Viton
Maximum Working Pressure: 400 bar
Operating Temperature : -40?C to 120?C
Material of Construction: AISI 316 SS
APPLICATIONS
Designed to protec t pressure instruments from
over pressure exceeding the specified pressure
range by sudden & excessive pressure fluctuation
from surge or spike.
This device blocks the higher pressure exceeding
the allowed value, Until it comes back to normal,
When system pressure becomes normal.
Hence this device safeguards the Pressure Instruments,
Gauges, Switches or Transmitters by blocking extra high
pressure.
Widely used in Mechanical Engineering and Plant
Construction, Power Stations , Mining, Environmental
Technology, Chemical and Petrochemical, On Shore
& Off Shore.
