Description
SPECIFICATION
- Performance @ 25°C (77 °F)
- Accuracy 1% FS, BFSL (includes non-linearity, hysteresis and non-repeatability)
- Stability 0.2% FS
- Thermal Error 1% FS
- Compensated Temperatures -10 to 75 ° C (14 to 167 ° F)
- Operating Temperatures -20 to 80 ° C (-4 to 176 ° F)
- Input
- Functional Supply Voltage /(Output) 10-30 VDC (0-5V, 4-20mA)
- 5 VDC (0.5-4.5V)
- 12-32 VDC (0-10V)
- Pressure Range 3 to 10,000 psi
- Proof Pressure 1.5 x full scale
- Burst Pressure 3 x full scale
- Current Consumption Approx 4mA for 0-5 & 0.5-4.5 voltage output, 11mA for 0-10 voltage output,
- 23mA for current output (4-20mA)
- Zero and Span Offset Tolerance 1.5%
- Shock 50g, 11ms, 1/2 sign
- Vibration 11g peak from 10 to 400 Hz
- Reverse Polarity Protection Yes
- Fatigue Life
- More than 4 million cycles
- Mechanical Configuration
- Pressure Port 1/4 NPT (standard) *
- Electrical Connection 9.4 mini DIN, 3 pin Packard *
- Ingress Rating IP65 with T-Direct standard 9.4 DIN cable IP66 with T-Direct standard Packard cable
- Housing 316 stainless steel
- Diaphragm Material 3-75psi = 316 SS, >75-1600psi = ceramic, >1600- 10,000psi = 17-4 SS
- Sealing Material Neoprene
- Approvals CE
